SL-125 Ex Combined Status Lights: Robust Signaling for Demanding Conditions

The SL-125 Ex combined status lights provide a flexible and adaptable signaling system designed for use in explosive atmospheres. Constructed entirely from stainless steel, this ATEX-certified product offers exceptional durability and corrosion resistance in the harshest industrial environments.

Key Features:

• ATEX Certified: Meets rigorous safety standards for hazardous areas.
• Robust Construction: Stainless steel housing and mounting plate for maximum durability.
• Versatile Configuration: Up to 5 customizable beacons with LED or Xenon options.
• Independent Control: Each beacon can be triggered individually or jointly.
• Remote Control: Optional telephone line control for added flexibility.
• Modular Design: Option to replace one beacon with a push button or junction box.

Applications:

The SL-125 Ex combined status lights are essential for visual signaling in various industries, including:

• Oil & gas
• Chemical
• Petrochemical
• Pharmaceutical
• Marine
• Offshore

Technical Specifications:

• Operating Temperature: T6 = -40°C + 55°C, T5 = -40°C + 60°C, T4 = -40°C + 70°C
• Material: Stainless steel
• IP Rating: IP66/67
• Enclosure Color: Red, Blue, Black, customizable
• Lens: Tempered borosilicate glass
• Power Supply: 12-48V DC or 100-240V AC
• Power Consumption: Xenon: 2-25W, LED: 5W
• Certification: Nemko 13 ATEX 1561X, IECEx NEM 13.0030X
